Finder Type 72.42 PRIORITY CHANGE RELAY, 2NO12A@250VAC

Description

Monitoring relays, Priority change, 2 NO, 12 A, AC/DC coil version, nominal voltage 24 V, operating from 16.8 to 28.8 V (AC) and from 16.8 to 32 V (DC), rated power 1.7 VA (AC) / 1.1 W (DC), AgNi, Options: Max. 150 kΩ, ambient temperature from -20 to +50 °C

Available variations:
– Control relay for alternating loads such as with pumps, compressors, air conditioning and refrigeration units, so as to share the duty and standby function and thereby even-out the wear across the equipment. It is a Multi-function relay (4 MI, ME, M2, M1 functions) with 2 independent NO contacts, 12 A outputs, 2 start inputs, isolated from the power supply.
– Control relay for alternating loads such as with pumps, compressors, air conditioning and refrigeration units, so as to share the duty and standby function and thereby even-out the wear across the equipment. It is a Multi-function relay (4 MI, ME, M2, M1 functions) with 2 independent NO contacts, 12 A outputs, 2 start inputs, isolated from the power supply.

Available models:

• 72.42-024: PRIORITY CHANGE RELAY, 2NO12A@250VAC, 24VAC/DC
• 72.42-230: PRIORITY CHANGE RELAY, 2NO12A@250VAC,110-240VAC/DC
