High Power relay, Faston 250 with flange mount, Number of poles: 1 NO + 1 NC, Contact circuit: 1 NO + 1 NC (SPST-NO + SPST-NC), 20 A, AgCdO, AC coil, 230 V, operating from 184 to 253 V, rated power 2.2 VA, resistance 7250 Ω, consumption 10.5 mA, holding voltage 184 V, must drop-out voltage 46 V, ambient temperature from -40 to +75 °C
Available variations:
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
Available models:
65.31-024-DC: POWER RELAY FLANGE MOUNT 24VDC, 1NO +1NC 20A@250VAC
65.31-0300-012DC: POWER RELAY FLANGE MOUNT 12VDC, 1NO 30A@250VAC
65.31-0300-024AC: POWER RELAY FLANGE MOUNT 24VAC, 1NO 30A@250VAC
65.31-0300-024DC: POWER RELAY FLANGE MOUNT 24VDC, 1NO 30A@250VAC
65.31-0300-230AC: POWER RELAY FLANGE MOUNT 230VAC, 1NO 30A@250VAC
65.31-230-AC: POWER RELAY FLANGE MOUNT 230VAC, 1NO +1NC 20A@250VAC
Finder Type 65.31 POWER RELAY FLANGE MOUNT 24VDC, 1NO +1NC 20A@250VAC
Description
High Power relay, Faston 250 with flange mount, Number of poles: 1 NO + 1 NC, Contact circuit: 1 NO + 1 NC (SPST-NO + SPST-NC), 20 A, AgCdO, AC coil, 230 V, operating from 184 to 253 V, rated power 2.2 VA, resistance 7250 Ω, consumption 10.5 mA, holding voltage 184 V, must drop-out voltage 46 V, ambient temperature from -40 to +75 °C
Available variations:
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
– “Power relay with mounting lugs on the back and Faston 250 connections Versions available: Type 65.31: 20 A 1 NO + 1 NC Type 65.31-4300: 30 A 1 NO”.
Available models:
