Low profile PCB relays, PCB/Plug-in – 5 mm pinning, 1 pole, CO (nPDT), 16 A, AgSnO2, DC coil, 24 V, operating from 16.8 to 36 V, rated power 0.4 W, resistance 1440 Ω, consumption 16.7 mA, holding voltage 9.6 V, must drop-out voltage 2.4 V, option: Production line 1, version: Flux proof (RT II), ambient temperature from -40 to +85 °C
Available variations:
– Low profile PCB relay 1 contact 16 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.
– Low profile PCB relay 1 contact 16 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.
Finder Type 41.61 PCB RELAY, LOW-PROFILE,1CO16A@250VAC
Description
Low profile PCB relays, PCB/Plug-in – 5 mm pinning, 1 pole, CO (nPDT), 16 A, AgSnO2, DC coil, 24 V, operating from 16.8 to 36 V, rated power 0.4 W, resistance 1440 Ω, consumption 16.7 mA, holding voltage 9.6 V, must drop-out voltage 2.4 V, option: Production line 1, version: Flux proof (RT II), ambient temperature from -40 to +85 °C
Available variations:
– Low profile PCB relay 1 contact 16 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.
– Low profile PCB relay 1 contact 16 A (5.0 mm pitch), suitable for mounting on PCB or 95 Series sockets. Equipped with AC or DC coil. 8 mm, 6 kV (1.2/50 μs) between coil and contacts. Cadmium-free contacts. Flux-proof: RT II standard, (also available in RT III version). Versions compliant with IECEx, ATEX (EX ec nC), HazLoc Class I Div. 2, Groups A, B, C, D – T4.
Available models:
