Crompton DL3N1 RJ12 Cable – Colour-Coded for Multi-Circuit Meters

Description

Colour-coded RJ12 patch cable for connecting DL3N1 3-in-1 CTs to the Crompton DL1-01 or TL1-01 multi-circuit power meters. Each cable has RJ12 connectors at both ends — plug one end into the DL3N1 CT and the other into the meter. Use different colours (blue, green, white) to easily identify which CT corresponds to which circuit on the meter.

Note: One cable required per DL3N1 CT. The DL1-01 uses 2 cables (2 circuits), the TL1-01 uses 3 cables (3 circuits). Choose the length that suits your switchboard layout.

Available lengths and colours:
– DL3N1-CABLE-1.5-BL: blue, 1.5m, 2x RJ12
– DL3N1-CABLE-1.5-GR: green, 1.5m, 2x RJ12
– DL3N1-CABLE-1.5-WH: white, 1.5m, 2x RJ12
– DL3N1-CABLE-3.0-BL: blue, 3.0m, 2x RJ12
– DL3N1-CABLE-3.0-GR: green, 3.0m, 2x RJ12
– DL3N1-CABLE-3.0-WH: white, 3.0m, 2x RJ12
– DL3N1-CABLE-4.0-WH: white, 4.0m, 2x RJ12

Related products:
– DL3N1 3-in-1 CTs: DL3N1-35, DL3N1-45, DL3N1-70 series
– DL3N1-RJ12X2: Double adapter for shorting unused CT inputs
– DL1-01: Dual load power meter
– TL1-01: Tri-load power meter
