Interval timer relay that energises the output for an adjustable time period after receiving a trigger pulse, then de-energises automatically. 2CO 5A@250VAC output contacts. Commonly used for timed lighting control, solenoid activation, and process timing applications.
Note: Requires ZB11 11-pin relay base socket (sold separately). For DIN rail retention, add CMAC Spring Clip. For delay on energise, see the RT10. For continuous on/off cycling, see the RT14.
Available models:
– RT12-2-1-115: 115VAC
– RT12-2-1-230: 230VAC
– RT12-2-1-230-10M: 10 min range, 230VAC
– RT12-2-2-024: 24VAC/DC
– RT12-NON-STK: non-standard range
Comadan RT12 Interval Timer Relay – 11 Pin Plug-In
Description
Interval timer relay that energises the output for an adjustable time period after receiving a trigger pulse, then de-energises automatically. 2CO 5A@250VAC output contacts. Commonly used for timed lighting control, solenoid activation, and process timing applications.
Note: Requires ZB11 11-pin relay base socket (sold separately). For DIN rail retention, add CMAC Spring Clip. For delay on energise, see the RT10. For continuous on/off cycling, see the RT14.
Available models:
– RT12-2-1-115: 115VAC
– RT12-2-1-230: 230VAC
– RT12-2-1-230-10M: 10 min range, 230VAC
– RT12-2-2-024: 24VAC/DC
– RT12-NON-STK: non-standard range
