Comadan RT10 Timer Relay – Delay on Energise, 11 Pin Plug-In
Description
Delay on energise timer relay with adjustable time delay. When the supply is applied, the relay waits for the set time before energising the output contacts (2CO 5A@250VAC). Commonly used for motor start sequencing, conveyor control, and HVAC staging.
Note: Requires ZB11 11-pin relay base socket (sold separately). For DIN rail retention, add CMAC Spring Clip. For delay on de-energise, see the RT16. For interval timing, see the RT12. For equal on/off cycling, see the RT14.
Available models:
– RT10-1-1-230-15S: 15 sec range, 230VAC
– RT10-2-1-115: 115VAC
– RT10-2-1-230: 230VAC
– RT10-2-2-024: 24VAC/DC
– RT10-NON-STK: non-standard range
