Three phase failure monitoring relay with built-in 3 second trip delay. Detects loss of any phase and trips the 1CO 8A@250VAC output after a 3 second delay, preventing nuisance trips from brief supply interruptions. 11 pin plug-in mounting. Commonly used on generator-fed supplies and sites with frequent brief power dips where instant tripping would cause unnecessary shutdowns.
Note: Requires ZB11 11-pin relay base socket (sold separately). For DIN rail retention, add CMAC Spring Clip. For instant phase fail detection (no delay), see the RP32. For DIN rail phase monitoring, see the FP31 or FP34.
Comadan RP32T Phase Fail Relay with 3 Second Delay – 11 Pin Plug-In
Description
Three phase failure monitoring relay with built-in 3 second trip delay. Detects loss of any phase and trips the 1CO 8A@250VAC output after a 3 second delay, preventing nuisance trips from brief supply interruptions. 11 pin plug-in mounting. Commonly used on generator-fed supplies and sites with frequent brief power dips where instant tripping would cause unnecessary shutdowns.
Note: Requires ZB11 11-pin relay base socket (sold separately). For DIN rail retention, add CMAC Spring Clip. For instant phase fail detection (no delay), see the RP32. For DIN rail phase monitoring, see the FP31 or FP34.
Available voltages:
– RP32T-400V: 1CO 8A@250VAC, 3 sec delay, 400VAC
– RP32T-415V: 1CO 8A@250VAC, 3 sec delay, 415VAC
Datasheet
Download
